i900 Mobility

Wireless Connection (Direct Connection via Router)

1. Launch Medit Link Express or Scan for Clinics.
2. Insert the battery and power on the scanner—the device will be detected automatically.
3. Select the scanner’s serial number on the screen:
4. Scan for Clinics: Automatic connection upon selection.
5. Medit Link Express: Wi-Fi password must be entered once during the first setup.

Wired Connection (Using the Hub)

1. Launch Scan for Clinics on your laptop.
2. Insert the battery and power on the scanner—the device will be detected automatically.
3. Select the serial number to complete the connection.

A Wi-Fi router is required for Direct Connection.

• Recommended specification: Wi-Fi 6E router.

Wi-Fi 6E utilizes the 6GHz band, offering higher speed and a more stable wireless connection compared to previous Wi-Fi standards.

• On PC or Mac, check Wi-Fi connection properties for protocol and frequency.
• The easiest way: Check the label on your router—it usually lists the model name and supported Wi-Fi standards (e.g., Wi-Fi 5, Wi-Fi 6, Wi-Fi 6E, AX1800).
• Alternatively, search the model number online for full specifications.
• For more technical details, check your device’s Wi-Fi settings for terms like 802.11ac (Wi-Fi 5) or 802.11ax (Wi-Fi 6).

Not necessarily, but we recommend using at least a Wi-Fi 6 or Wi-Fi 6E router for better stability and faster data transmission. This ensures a seamless scanning experience without interruptions.

Yes. Existing i900 tips are fully compatible with i900 Mobility (i900M).

The i900 Mobility is equipped with two physical buttons, each serving different purposes:

• Top Button (Scan Button): Press once to start or stop scanning. Additional functions can be triggered by double-pressing, triple-pressing, or long-pressing. These actions can be customized in the settings menu for user convenience.
• Bottom Button (Control Button): This button allows you to easily manipulate the scanned data—rotate, move, zoom in/out—without a mouse or touchscreen. Its intuitive design makes it possible to review and adjust scans directly from the scanner, improving workflow efficiency.

Yes. You can remove the hub and switch to Direct Connection via a Wi-Fi router at any time.
To switch back, reconnect the hub to the laptop, and the scanner will automatically revert to the wired connection mode.
